1 high-speed centrifugal principle, dehydration speed, high dehydration, without any damage to the fabric.
2 The product is equipped with a brake system that allows reliable brake drum.
3 The product can also be used for the dehydration of other small parts, but can be used to take a long time to separate particles and coarse particles in suspension.
4 cylinder made of stainless steel, acid, alkali, durable, long life.
| 型號 Model | TL-15 | TL-25 | TL-35 | TL-50 | TL-70 | TL-100 |
|---|---|---|---|---|---|---|
|
脫水容量(kg) Dewatering capacity |
15 | 25 | 35 | 50 | 70 | 100 |
|
脫水轉速(r/min) dehydration speed |
900 | 850 | 830 | 786 | 780 | 770 |
|
脫水筒尺寸(mm) Inner cylinder size |
Φ440×3700 | Φ5700×330 | Φ640×330 | Φ850×390 | Φ950×400 | Φ1000×380 |
|
電機功率(kw) motor power |
1.5 | 1.1 | 1.5 | 4 | 5.5 | 7.5 |
|
額定電壓(V) rated voltage |
220/380 | 380 | 380 | 380 | 380 | 380 |
|
外形尺寸(mm) Dimension |
830×530×830 | 1200×1000×650 | 1300×1100×700 | 1650×1300×850 | 1700×1400×900 | 1850×1450×1000 |
|
整機重量(kg) Weight |
125 | 350 | 400 | 850 | 1200 | 1500 |
|
 |
 |
 |
 |
|
|
|
